Features:
• Applicable for usage in more than 180 countries
• Universal socket outlet + 2 round / flat / slant-fat plug pins socket outlet
• Child safety shutter
• Flame retardant PC casing
• Power indicator light
• Cartridge fuse protection and spare fuse
• 1 x USB-C GaN III PD & QC 3.0 port (45W)
• 3 x USB-C port
• 1 x USB-A port
USB Protection
• Overcurrent
• Over Temperature
• Overload
• Over Voltage
• Under Voltage
• Short-circuit
• Chip Protection
Specifications
Rated Input: 100~250V, 50/60Hz
Fuse Rating: 10A
Max Power: 1000W at 100V AC, 2500W at 250V AC
Total USB Output: 45W Max.
USB-C1 Single Output: 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/2.25A (45W Max.) (PPS: 3.3 - 16V/3A, 3.3 - 21V/2.25A)
USB-C2 / C3 / C4 Single Output: 5V/3A (15W Max.)
USB-A Single Output: 5V/2.4A (12W Max.)
USB-C1 + C2 / C3 / C4 Output: 30W + 15W
USC-C1 + A Output: 30W + 12W
USB-C2 / C3 / C4 + A Output: 15W
USB-C2 + C3 / C4 Output: 15W
USB-C1 + (C2 + C3 / C4) Output: 30W + 15W
USB-C1 + (C2 / C3 + A) Output: 30W + 15W
USB-C2 + C3 / C4 + A Output: 15W
USB-C2 + C3 + C4 Output: 15W
USB-C1 + (C2 + C3 + C4 / A) Output: 30W + 15W
USB-C2 + C3 + C4 + A Output: 15W
USB-C1 + (C2 + C3 + C4 + A) Output: 30W + 15W
Product Dimension: Lcm x Wcm x Hcm
Product Weight: KG
How to use?
1. Press down and slide out the “UK/ AUS/ EU/ US” button to slide out the “UK/ AUS/ EU/ US” plug-pin. Ensure the plug pin is fully-extended and locked in position.
2. To retract, press down and hold the “Retract” button;
3. Then press down and slide in the “UK/ AUS/ EU/ US” button to retract the “UK/ AUS/ EU/ US” plug-pin back to its
original position.
Attention:
Due to the nature of Power Delivery (PD) charging function, while USB-C PD port is applied for charging operation with other USB-A port, it is normal for the USB-A charging device to temporarily cease charging for 1-2 seconds and resume charging again when the USB-C charging device is connected or disconnected from the USB-C PD port.
